Hygenic Tube and Fittings
Stainless Steel Hygienic Tube to ASTM A270 Grades 304L & 316L. Available in Bright Annealed or with Satin Polished O/D
| Size | KG/Metre |
|---|---|
| 4" O/D X 14SWG | 5.02 |
| 4" O/D X 16SWG | 4.04 |
| 3" O/D X 16SWG | 3.02 |
| 2 1/2" O/D X 16SWG | 2.51 |
| 2" O/D X 16SWG | 1.99 |
| 1 1/2" O/D X 16SWG | 1.45 |
| 1" O/D X 16SWG | 0.97 |
| 3/4" O/D X 16SWG | 0.72 |
Stainless Steel Hygienic Tube to DIN 11850 - UN-ANNEALED - Grade 316L. Available Descaled or with Satin Polished O/D
| Size | KG/Metre |
|---|---|
| 4" O/D X 14SWG | 5.02 |
| 4" OD X 2.0mm | 4.98 |
| 4" OD X 1.5mm | 3.75 |
| 3" OD X 1.5mm | 2.8 |
| 2 1/2" OD X 1.5mm | 2.33 |
| 2" OD X 1.5mm | 1.85 |
| 1 1/2" OD X 1.5mm | 1.37 |
| 1" OD X 1.5mm | 0.9 |
Stainless Steel Hygienic Tube to DIN 11850 - UN-ANNEALED - Grade 304. Available Descaled or with Satin Polished O/Dt
| Size | KG/Metre |
|---|---|
| 1" OD X 1.5mm | 0.9 |
| 1 1/2" OD x 1.5mm | 1.37 |
| 2" OD X 1.5mm | 1.85 |
